ADI 4-20mA感應電流環路數模轉化成器

發布公告周期：2022-03-24 16:34:54     瀏覽網頁：1860

ADI一體化型系統性解決處理工作方案將數模改變器和能夠器一體化型到是一個處理器中，需要直觀從數值域提高所必需要的輸出電壓。ADI的工農業數模轉變器和驅動軟件器的產品國產供給普遍性的可編譯程序工作輸出，從功率量漏電開關移動通訊的標淮4mA到20mA到把握閥調低的±10V。ADI化學工業準換器具備優良的調節器意義和領先于的片上確診，以主要底限地提升平臺的普通經營模式日期，杜絕一部分傳統意義式離散標準架構常需用的名貴的多種校零源程序。

遠程管理檢驗和機系統化內部故障解決具備木制托盤數據表格，以提升 機系統化的安全可靠性全部性方法。ADI給出了幾這方面的HART調試解調器和4mA到20mA轉變成器，能否直接的使用，以控制可靠性，精確度高和HART理財產品會備案的消除計劃書。ADI的防止策劃方案可以需求環路和非環路輸電網智能變送器、隔絕和非隔絕模擬網I/O卡的規定標準需要。

南京市立維創展科學是ADI的代銷商，重要批售調大器、直線企業品牌的、數據表格轉化器、音頻系統播放企業品牌的、寬帶網絡企業品牌的、掛鐘和按時IC、電信光纖通訊技術物品、模塊和間斷、MEMS和傳調節器器、電源開關和熱經管、補救器和DSP、頻射和多邊形整理器、按鈕開關和管理器等。大部件類產品，均提供數據期貨倉庫要貨。

商品詳情知曉ADI芯片請點擊：//www.myloveidc.com/brand/25.html


成品款型

ChannelsResolutionDAC TypeTUE Iout (typ)Output RangeDAC FeaturesSupply Voltage Range


bits
%


AD5423116Current Out, Voltage Out
±10V, ±12V, ±20mA, ±24mA, ±5V, ±6V, 0 to   5V, -0.3V to 5.7V, -0.4V to 11.6V, 0mA to 20mA, 0mA to 24mA, 0V to 10V, 0V to   12V, -1mA to 22mA, 4mA to 20mA4-20mA, HART Connectivity-33V to +33V
AD74412R416Current Out, Voltage Out0.20mA to 25mA, 0V to 11V4-20mA14V to 26.4V, 2.7V to 5.5V
AD74413R416Current Out, Voltage Out0.20mA to 25mA, 0V to 11V4-20mA14V to 26.4V, 2.7V to 5.5V
AD5413114Current Out, Voltage Out
±10.5 V, ±12.6 V, 0mA to 24mA4-20mA, HART Connectivity-33V to +33V
AD5758116Current Out, Voltage Out
±10V, ±12V, ±20mA, ±24mA, ±5V, ±6V, 0mA   to 20mA, 0mA to 24mA, 0V to 10V, 0V to 12V, 0V to 5V, 0V to 6V, -1mA to 22mA,   4mA to 20mA4-20mA, DAC, Dynamic Power Control, HART   Connectivity, Integrated ADC, LDAC Pin-33V to 0V, 5V to 33V, 7V to 33V
ADFS5758116Current Out, Voltage Out
±10V, ±12V, ±20mA, ±24mA, ±5V, ±6V, -0.3V   to 5.7V, -0.4V to 11.6V, 0mA to 20mA, 0mA to 24mA, 0V to 10V, 0V to 12V, 0V   to 5V, 0V to 6V, -1mA to 22mA4-20mA, DAC, Functional Safety, HART   Connectivity, Precision DACs-12V to -24V, -33V to +33V
AD5735412Current Out, Voltage Out0.022±10V, ±5V, 0mA to 20mA, 0mA to 24mA, 0V   to 10V, 0V to 5V, 4mA to 20mA4-20mA, CLR Pin, Double-Buffered, LDAC   Pin, Read-Back, Reset/Clear, SDO Pin-26.4V to -10.8V, 4.5V to 5.5V, 9V to 33V
AD5737412Current Out0.0220mA to 20mA, 0mA to 24mA, 4mA to 20mA4-20mA, CLR Pin, Double-Buffered, HART   Connectivity, LDAC Pin, Read-Back, Reset/Clear, SDO Pin2.7V to 5.5V, 4.5V to 5.5V, 9V to 33V
AD5755416Current Out, Voltage Out0.009±10V, ±5V, 0mA to 20mA, 0mA to 24mA, 0V   to 10V, 0V to 5V, 4mA to 20mA4-20mA, CLR Pin, Double-Buffered, LDAC   Pin, Read-Back, Reset/Clear, SDO Pin-26.4V to -10.8V, 4.5V to 5.5V, 9V to 33V
AD5755-1416Current Out, Voltage Out0.009±10V, ±5V, 0mA to 20mA, 0mA to 24mA, 0V   to 10V, 0V to 5V, 4mA to 20mA4-20mA, CLR Pin, Double-Buffered, HART   Connectivity, LDAC Pin, Read-Back, Reset/Clear, SDO Pin-26.4V to -10.8V, 4.5V to 5.5V, 9V to 33V
AD5757416Current Out0.0090mA to 20mA, 0mA to 24mA, 4mA to 20mA4-20mA, CLR Pin, Double-Buffered, HART   Connectivity, LDAC Pin, Read-Back, Reset/Clear, SDO Pin4.5V to 5.5V, 9V to 33V
AD5421116Current Out0.0643.2mA to 24mA, 3.8mA to 21mA, 4mA to 20mA4-20mA, Double-Buffered, LDAC Pin, On   Chip Temp Sensor, Read-Back, SDO Pin5.5V to 52V
AD5410112Current Out0.080mA to 20mA, 0mA to 24mA, 4mA to 20mA4-20mA, Daisy Chain, HART Connectivity,   LDAC Pin, Read-Back, Reset/Clear, SDO Pin10.8V to 60V
AD5412112Current Out, Voltage Out0.08±10V, ±5V, 0mA to 20mA, 0mA to 24mA, 0V   to 10V, 0V to 5V, 4mA to 20mA4-20mA, Daisy Chain, HART Connectivity,   LDAC Pin, Read-Back, Reset/Clear, SDO Pin10.8V to 40V, -26.4V to 0V
AD5420116Current Out0.080mA to 20mA, 0mA to 24mA, 4mA to 20mA4-20mA, Daisy Chain, HART Connectivity,   LDAC Pin, Read-Back, Reset/Clear, SDO Pin10.8V to 60V
AD5422116Current Out, Voltage Out0.08±10V, ±5V, 0mA to 20mA, 0mA to 24mA, 0V   to 10V, 0V to 5V, 4mA to 20mA4-20mA, Daisy Chain, LDAC Pin, Read-Back,   Reset/Clear, SDO Pin10.8V to 40V, -26.4V to 0V
AD421116Current Out
4mA to 20mA4-20mA2.95V to 5.05V
AD420116Current Out, Voltage Out
±10V, ±5V, 0mA to 20mA, 0mA to 24mA, 0V   to 10V, 0V to 5V, 4mA to 20mA4-20mA12V to 32V
